| Specification | HST1001 | HST1201 | HST1501 | HST1506 | HST1701 | HST2105 |
|---|---|---|---|---|---|---|
| Size | 10.1" | 12.1" | 15.1" | 15.6" | 17.1" | 21.5" |
| Resolution | 1280 × 800 | 1024 × 768 | 1024 × 768 | 1920 × 1080 | 1280 × 1024 | 1920 × 1080 |
| Touch | Resistive / Capacitive Touch Screen | |||||
| Viewing Angle | -85° ~ 85° (H), -85° ~ 85° (V) | |||||
| Backlight | LED | |||||
| Backlight Life | 30,000 Hours | |||||
| LCD | TFT | |||||
| Processor (SoC) |
Intel Celeron J1900, 2.0 GHz, Quad Core intel core i5-1135G7, Up to 4.20 GHz, Quad core intel core i7-1165G7, Up to 4.70 GHz, Quad core Intel Core i5-8250U, Up to 3.4 GHz, Quad core Intel Core i7-8550U, Up to 4.0 GHz, Quad core |
|||||
| Memory | Onboard DDR4 up to 32 GB | |||||
| LAN | 2× GbE RJ45 Intel i211-AT | |||||
| I/O |
4× USB 3.0 2× DB-9 COM1 & COM2 (RS232/422/485) 2× 3-Wire COM3 & COM4 RS232/485 (Phoenix Terminal) 2× 3-Wire COM5 & COM6 RS232 (Phoenix Terminal) Audio Line Out, 1× HDMI, 1× Phoenix Terminal (DC 9–36V) |
|||||
| Storage | Up to 2 TB - SSD | |||||
| Expansion |
1× Full Height Mini-PCIe (SIM slot, supports 3G/4G) 1× Half Height Mini-PCIe (Wi-Fi/Bluetooth) |
|||||
| Watchdog Timer | 1–255 Seconds Programmable | |||||
| OS Support | Windows 7/8/10/11, WES, Linux | |||||
| Material | Aluminum Alloy | |||||
| Installation | VESA 75 / Panel Mount | |||||
| Weight | 2.7 kg | 3.2 kg | 4.5 kg | 4.6 kg | 5.7 kg | 6.0 kg |
| Working Temperature | -20°C ~ 60°C | |||||
| Storage Temperature | -30°C ~ 70°C | |||||
| Humidity | 10–90% @30°C, No Condensation | |||||
| Certifications | IP65, CE, FCC, RoHS | |||||
| Code | Description |
|---|---|
| HST1001 | 10.1” Fanless IPC, Celeron J1900/i5/i7, 8GB RAM, 128GB SSD, Win/Linux, IP65 |
| HST1201 | 12.1” Panel PC, Industrial Touch, i5-8250U, Dual LAN, VESA Mount, CE/RoHS |
| HST1501 | 15.1” Touch IPC, i7-8550U, 4×USB, 6×COM, 1×HDMI, Wide Temp Support |
| HST1506 | 15.6” Full HD Display, Capacitive Touch, Intel Core i5/i7, 4G/WiFi Expansion |
| HST1701 | 17.1” Industrial Panel PC, RS232/485, Audio Out, Fanless, Wide Voltage Input |
| HST2105 | 21.5” High-Performance IPC, Full HD, RAID Support, SSD+SATA, Windows/Linux |
